Home > 2014 BADBOY MOWERS > DIESEL > 2014 DIESEL SEAT FRAME 2014DSEATFRM
2014DSEATFRM / 2014DSEATFRM   Alternative Views:	Product Code: 2014DSEATFRM 2014 DIESEL SEAT FRAME: ITEM# 1, 069-8054-00, Brake Handle Kit ITEM# 2, 062-8013-00, Filter Head-Hydraulic Filter ITEM# 3, 063-8014-00, Hydraulic Filter-All Models ITEM# 4, 024-5050-00, Filter Head Fitting, 1/2 x 1/2 ITEM# 5, 077-8073-00, Safety Switch ITEM# 6, 018-8059-00, 5/16-18x1-3/4 GR 5 Hex Bolts ITEM# 7, 080-7000-00, 2007 Diesel Seat Frame ITEM# 8, 068-8050-00, Battery - Diesel Models (Purchase at Local Dealer) ITEM# 9, 018-8052-00, 1/4-20 X 3/4 GR 5 Hex Bolts ITEM# 10, 019-4008-00, 1/4 Lockwasher Zinc ITEM# 11, 013-9002-00, 5/16-18 Hex Flange Nuts Zinc w ITEM# 12, 025-6041-00, Switch Block Plastic ITEM# 13, 064-8055-00, Short Brake Cable ITEM# 14, 018-8056-00, 10-24x1/2 Buttonhead SCS 18-8 ITEM# 15, 067-2010-00, Aluminum Hydraulic Tank ITEM# 16, 066-8050-00, Hydraulic Tank Cap w/Dipstick ITEM# 17, 064-8056-00, Long Brake Cable ITEM# 18, 051-8063-00, 3/8 Clear Hose PRICED PER FOOT ITEM# 19, 051-8064-00, 1/2 Clear Braided Hose Priced / Foot ITEM# 20, 055-8018-00, Throttle - All Diesel Models ITEM# 21, 055-8018-75, Diesel Thottle Cable ONLY ITEM# 22, 034-1000-00, Spring Cushion-2013 Models ITEM# 23, 077-6000-00, Momentary Start Switch ITEM# 24, 014-6000-00, Start Switch Boot - Diesel ITEM# 25, 021-8059-00, Heat Warning Piezo Buzzer ITEM# 26, 015-0015-00, Auto Shut Down for Cat Diesels ITEM# 27, 013-5019-00, 10-24 Nylon Insert Locknut Zin ITEM# 28, 018-5200-00, 10-24 X 5/8 BS C/S 18-8 SS ITEM# 29, 013-8039-00, 1/4-20 Hex Nuts Zinc ITEM# 30, 072-8066-00, 1/2 Hose Clamp ITEM# 31, 072-8065-00, 3/8 Hose Clamp - CTB-16-STFS ITEM# 32, 019-5029-00, 3/8 USS Flat Washer Zinc ITEM# 33, 013-5201-00, 3/8-16 Hex Flange Nuts Zinc w/ ITEM# 34, 018-5040-00, 3/8-16 X 1-1/4 GR 5 Hex Bolt ITEM# 35, 043-8929-00, Battery Hold Down ITEM# 36, 064-4001-00, Black Battery Cable - Diesel ITEM# 37, 064-4000-00, Red Battery Cable - Diesel ITEM# 38, 026-2006-00, 2006 Seat Plate ITEM# 39, 019-6042-00, .360 ID Plastic Washer ITEM# 40, 013-8049-00, 5/16-18 Nylon Flange Nut ITEM# 41, 018-8065-00, 5/16-18 X 1 Carriage Bolt Zinc ITEM# 42, 071-4050-00, Grammer Suspension Seat ITEM# 43, 013-9002-00, 5/16-18 HEX FLANGE NUTS ZINC W ITEM# 44, 018-0011-00, 1/4-20 x 2 Hex Bolt ITEM# 45, 013-8049-00, 5/16-18 NYLON FLANGE NUT ITEM# 46, 013-9001-00, 1/4-20 Hex Flange Nuts Zinc w/ ITEM# 47, 034-1075-00, Torsion Spring-2012 Seat Latch ITEM# 48, 019-6042-00, 360 ID PLASTIC WASHER ITEM# 49, 031-0200-00, SEAT LATCH LEVER ITEM# 50, 018-0012-00, 5/16-18 X 2 HEX C/S (GR.5) ZC ITEM# 51, 014-2009-00, Cooler Cover 2009 thru 2011 ITEM# 52, 030-7042-00, 5/16 x 3/4 Hex Washer Type F ITEM# 53, 018-2018-00, 1/2 x 3 1/2 Flange Bolt - Gr 8 ITEM# 54, 013-5300-00, 1/2-13 Hex Fange Nuts Zinc w/ ITEM# 55, 036-5300-00, Seat Switch Adaptor - Pup Qty:

Description   Features Above you will see the 2014 Diesel Seat Assembly drawing. If you scroll down to the larger view, of the 2014 Diesel parts, you can point and click on the 2014 Diesel part that you need for your Bad Boy Mower. Or you can look at the drop down menu for a list of the parts in the picture for the 2014 Diesel Bad Boy Mower. Find all of your 2014 Diesel Bad Boy Mower Parts here at www.badboylawnmowerparts.com. Still cannot find your 2014 Diesel Parts? Call us! 904-259-5494 We strive to have the Bad Boy Parts that you need. We stock 1000s of Bad Boy Parts for your Bad Boy Mower. If we don't stock the Bad Boy Part you need for your Bad Boy Mower, we can still get the Bad Boy Part to you by direct ship from Bad Boy Mowers. Related Items 2014 DIESEL BACK PUMP COVER 2014DBPCOV 2014 DIESEL COMPACT DIESEL FRAME 2014DCMPCTD 2014 DIESEL HYDRAULIC COOLER 2014DHYDCOOL 2014 DIESEL 72 DECK ASSEMBLY 2014D72DK 2014 DIESEL SUSPENSION & WHEEL MOTOR 14DIESUSBCKPUMP 2014 DIESEL DECALS 2014DDECAL 2014 DIESEL RADIATOR ASSEMBLY 2014DRADASSY 2014 DIESEL 61 DECK ASSEMBLY 2014D61DK
